Place of Origin: | China |
Brand Name: | Yuncore |
Certification: | CE,FCC,ROHS |
Model Number: | CPE880 |
Minimum Order Quantity: | 100 PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Giftbox + Carton box |
Delivery Time: | 4 working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 1000 PCS/ WEEK |
Material: | ABS | Chipset: | AR9344 |
---|---|---|---|
Flash: | 8M | RAM: | 64M |
Port: | 1 * 10/100Mbps WAN, 1 * 10/100Mbps LAN | Antenna: | 15 DBi Panel Antenna |
Standard: | IEEE802.11a/n | Frequency: | 5150~5825MHz |
High Light: | outdoor cpe device,5.8 ghz wireless bridge |
300Mbps PTP 5KM Distance 5.8G 11AC Outdoor Wireless CPE / Wireless Bridge
CPE-880 is an 5.8G outdoor CPE/Wi-Fi Bridge with 300Mbps data rate. Comply with IEEE802.11a/n standard, Atheros chipset, it supply you a stable and freely Wi-Fi networking. What’s more, with 15dBi high gain antenna, 30dBm high power output power, the Wi-Fi distance more than 5000 meters.
CPE-880 with wonderful RF performance, receive sensitivity can be -90dBm, then data rate can be 300Mbps, improved hardware Wi-Fi interference, it is best choice for video and security industrial.
Meantime, it support Power over Ethernet, support 24V passive PoE, easy in setup even no power socket nearby. With LED light show signal strength, easy to find a suitable place for outdoor CPE, save much human work and cost. With water proof case, it is best choice for outdoor Wi-Fi projects.
Features:
More RF Power, More WiFi Range
More RF Power up to 1000mW, equipped with 15dBi Panel Antenna, PTP WiFi distance up to 3500 meters. Meanwhile, the RF Power is adjustable for different country and different application
300Mbps High data rate
Comply with IEEE 802.11a/n standard,5.8G, 300Mbps High data rate
Multi Working mode suit for different application
CPE880 support multi operation mode such as Gateway, Wireless AP, Repeater, WISP, WDS pass through mode to meet with multi application for different environment.
PoE Power and DC Power together make installation flexibility
CPE880 Support 24V passive PoE for some areas where power outlets are not readily available; It support DC power supply for some area near to power socket, flexibility in installation
Excellent Outdoor Weatherproof and Lighting Protection
With an outdoor waterproof and dustproof enclosure,buidling in lighting protection IC, CPE880 can be used in various weather conditions for stable performance
Spec:
Standard | IEEE802.3, IEEE 802.11n, IEEE 802.11a |
Frequency | 5.020 - 6.1000 GHz |
Channel | CH4 ~CH220 |
Modulation | OFDM = BPSK,QPSK,16-QAM,64-QAM;DSSS = DBPSK,DQPSK,CCK |
Data Rate |
11n: up to 300Mbps(dynamic) 11a: up to 54Mbps(dynamic) |
Protocol | CSMA/CA,CSMA/CD,TCP/IP,ICMP,NAT,PPPoE, DHCP , Wired static , Wi-Fi Client , UDP, DDNS, |
Operation Mode | AP, Gateway, Bridge, WISP |
Security |
64/128bit WEP WPA(AES,TKIP with IEEE 802.1x) WPA2(AES,TKIPwith IEEE 802.1x) WPS |
RF Output Power |
802.11a:54M 20±2 DB,6M 23±2 DB. 802.11n HT20:MCS7 19±2 DB, MCS0 22±2 DB. 802.11n HT40:MCS7 19±2 DB, MCS0 22±2 DB. |
Receive Sensitivity |
802.11a: -70dbm@ 54Mbps; -89dbm@ 6Mbps. 802.11n HT20: -65dbm@MCS7, -83dbm@MCS0 . 802.11n HT40: -62dbm@MCS7, -80dbm@MCS0 . |
Antenna | 15dBi MIMO Panel antenna |
Size(mm) | L: 257mm, W: 87mm, H: 38 mm |
Weight | 327g |
Working Temperature | -40°C ~ 55°C |
Storage Temperature | -40°C ~ 70°C |
Humidity | 10% ~ 90% (Non-condensing) |
Interface |
1 * RJ-45 WAN Port 1 * RJ-45 LAN Port 1 * Reset Button 1 * DC Jack 1 * WDS Switch Button |
Power | Output: DC12V(POE 24V), 1A; Input: 110V/220V |
LED Light | Power, Wi-Fi, WAN, LAN,Signal Strength |
Working Diagram:
