Place of Origin: | China |
Brand Name: | 100% Neutral |
Certification: | CE, FCC, RoHS, TUV |
Model Number: | XD4200 |
Minimum Order Quantity: | 500PCS |
---|---|
Price: | $45/PCS~$49/PCS |
Packaging Details: | Appearance Size: 198mm*198mm*32mm |
Delivery Time: | 5~8 days |
Payment Terms: | T/T |
Supply Ability: | 60000PCS per month |
Chipset: | Qualcomm | Frequency: | Dual-Band |
---|---|---|---|
Data Rate: | 1200Mbps | Wave: | Wave 2.0 |
RF Power: | ≤30dBm | ||
High Light: | wireless ac access point,ceiling access point |
Description:
Model XD4200 is a Qualcomm Chipset high power industrial Ceiling Wireless Access Point with the next generation 802.11ac Wi-Fi standard, combined 1200Mbps Wi-Fi speed over 2.4GHz(300Mbps) and 5GHz(900Mbps), support Wave2, equipped Gigabit WAN & LAN port, fast Ethernet data rate make more than 100 end users can access into XD4200 with faster Ethernet, make them enjoy seamless HD movies, streaming, online gaming, wireless security, and other bandwidth-intensive tasks, widely be used in school, hospital, hotel, office, shipping mall...
High Power for more range and stable signal:
Designed in two line Power Amplifier on PCB board, the power can be 1000mW high power, 5dBi MIMO high gain antenna, together with Ceiling mount, greatly increase the wireless range and supply the stable Wi-Fi signal for users.
Wave 2 Technology:
With Wave 2 Technology, it adopts 256QAM modulation, support MU-MIMO (Multi-User Multiple-Input Multiple-Output), 160MHz Frequency, greatly to improved the communication efficiency.
Power over Ethernet:
XD4200 has integrated IEEE802.3at Power over Ethernet (PoE), for easy installation and lower cost. So it can be installed in areas where power outlets are not readily available, eliminating the mess of altering existing network infrastructure.
Access Controller System & Cloud Management System:
With Access Control System, easily access advanced network settings through PC, like AP status monitor, change IP address, ESSID, Channel, Password, upgrade firmware, backup and restore...
Then work with Cloud Management System, easy to do central and remote management, advertisement and multiple captive portal authentications make this AP more professional in Wi-Fi Projects.
Main Features:
Product Spec.:
Hardware: | |||||
Chipset | Qualcomm QCA9563 + QCA9886 +QCA8334 | ||||
Standard | 802.11ac/b/g/n, MIMO technology | ||||
Memory | 128MB DDR2 RAM | ||||
Flash | 16MB | ||||
Interface | 1 * 10/100 /1000Mbps RJ45 WAN Port | ||||
1 * 10/100 / 1000Mbps RJ45 LAN Port | |||||
1 * Reset button, press 15 seconds to revert to a default setting | |||||
Antenna | Build in 5dBi MIMO Antenna | ||||
Power consumption | 48V PoE<30W | ||||
Size | 198*198*28mm | ||||
Weight | |||||
RF Data | |||||
Frequency |
2.4G:802.11b/g/n; 5GHz:802.11a/n/ac | ||||
2.4GHz, 5GHz | |||||
Country code | FCC,IC,ETSI,MKK,MKK1,MKK2,MKK3,NCC,RUSSIAN,CN | ||||
Modulation | OFDM = BPSK,QPSK, 16-QAM, 64-QAM | ||||
DSSS = DBPSK, DQPSK, CCK | |||||
Throughput | 1200Mbps | ||||
2.4GHz RF Power | 802.11b | 11M | 28±2dBm | 1M | 29±2dBm |
802.11g | 54M | 27±2dBm | 6M | 29±2dBm | |
802.11n HT20 | MCS7 | 26±2dBm | MCS0 | 28±2dBm | |
802.11n HT40 | MCS7 | 25±2dBm | MCS0 | 27±2dBm | |
5.8G RF Power | 802.11a | 54M | 23±2dBm | 6M | 25±2dBm |
802.11n HT20 | MCS7 | 22±2dBm | MCS0 | 24±2dBm | |
802.11n HT40 | MCS7 | 21±2dBm | MCS0 | 24±2dBm | |
802.11ac HT80 | MCS9 | 20±2dBm | MCS0 | 23±2dBm | |
2.4G Receive Sensitivity | 802.11b | 11M | -85dBm | 1M | -94dBm |
802.11g | 54M | -72dBm | 6M | -90dBm | |
802.11n HT20 | MCS7 | -70dBm | MCS0 | -88dBm | |
802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm | |
5.8G Receive Sensitivity | 802.11a | 54M | -72dBm | 6M | -90dBm |
802.11n HT20 | MCS7 | -70dBm | MCS0. | -88dBm | |
802.11n HT40 | MCS7 | -68dBm | MCS0. | -86dBm | |
802.11ac HT80 | MCS9 | -58dBm | MCS0. | -85dBm | |
EVM |
2.4G: 802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28 dB 5.8G: 802.11a: ≤-25dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB |
||||
PPM | ±20ppm | ||||
Max Users | 128+ | ||||
Firmware Features: | |||||
Operation mode | Wireless AP, Gateway, WISP, Wi-Fi Repeater | ||||
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access) | ||||
Wireless Security | 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption | ||||
SSID | Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G) | ||||
Firewall | DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
||||
Protocols | IPv4 | ||||
Others: | |||||
Package Contents |
1200Mbps Dual Band wireless access point Ethernet Cable Quick Installation Guide Setting Accessory |
||||
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux | ||||
Environment |
Operating Temperature: -30~55 ℃ Max Operating Temperature: -40~70 ℃ Storage Temperature: -40~70 ℃ Humidity: 5%~95% non-condensing |
||||
Management | Firmware GUI, Remote Management, WLAN Controller, Cloud Management System |
