Tri Band Waterproof Outdoor Wireless Access Point 2200Mbps Wi-Fi Base Station

Tri Band Waterproof Outdoor Wireless Access Point 2200Mbps Wi-Fi Base Station

    • Tri Band Waterproof Outdoor Wireless Access Point 2200Mbps Wi-Fi Base Station
    • Tri Band Waterproof Outdoor Wireless Access Point 2200Mbps Wi-Fi Base Station
  • Tri Band Waterproof Outdoor Wireless Access Point 2200Mbps Wi-Fi Base Station

    Product Details:

    Place of Origin: China
    Brand Name: 100% Neutral
    Certification: CE, FCC, RoHs, TUV
    Model Number: HW-AP2200

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Price: $170/PCS~$183/PCS
    Packaging Details: Product Size: 183mm*183mm*43mm
    Delivery Time: 7-working days
    Payment Terms: T/T,, L/C
    Supply Ability: 10000pcs per month
    Contact Now
    Detailed Product Description
    Chipset: Qualcomm IPQ4019+QCA9886+QCA8075

    Main Features:

    • Comply with IEEE 802.11ac/b/g/n, tri-band, 2200Mbps Data Rate
    • 1*10/100/1000Mbps WAN Port, PoE support, water-proof
    • 300mW high power can connect with external antenna for stronger signal strength and more wireless coverage, 32M Flash, 512M DDR3 RAM, more user, more stable
    • Support IEEE 802.3at PoE standard
    • Support SSID broadcasting, Multi SSID up to 12 (4 SSID in 2.4GHz, 8 SSID in 5GHz)
    • Support Gateway (PPPOE, static IP, dynamic IP), Wireless AP, Repeater, WISP operation mode
    • Support DDNS, VPN pass through, Port forwarding and DMZ host

    Product Spec.:



    Hardware:
    ChipsetQualcomm IPQ4019+QCA9886+QCA8075
    Standard802.11ac/b/g/n, MU-MIMO technology
    Memory512MB DDR3 RAM
    Flash32MB
    Interface1 * 10/100 /1000Mbps RJ45 WAN Port
    1 * 10/100 / 1000Mbps RJ45 LAN Port (Inside of shell)
    1 * Reset button, press 10 seconds to revert to the default setting
    Antenna6 * N-type connector, works with 6PCS 6dBi Omni antennas.
    Power consumption48V PoE<30W
    Size183mm*183mm*43mm
    Water Proof LevelIP65
    RF Data



    Frequency

    2.4G: 802.11b/g/n: 2.4GHz – 2.484GHz
    5GHz:802.11a/n/ac MIMO: 5.150GHz~5.850GHz
    ModulationOFDM = BPSK,QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM
    DSSS = DBPSK, DQPSK, CCK
    Throughput2200Mbps
    2.4G RF Power (IPQ4019)802.11b11M23±2dBm1M25±2dBm
    802.11g54M22±2dBm6M24±2dBm
    802.11n HT20MCS721±2dBmMCS023±2dBm
    802.11n HT40MCS721±2dBmMCS023±2dBm

    5G RF Power
    (IPQ4019)

    802.11a54M19±2dBm6M21±2dBm
    802.11n HT20MCS718±2dBmMCS020±2dBm
    802.11n HT40MCS718±2dBmMCS020±2dBm
    802.11ac HT80MCS917±2dBmMCS019±2dBm

    5G RF Power
    (QCA9886)

    802.11a54M19±2dBm6M21±2dBm
    802.11n HT20MCS718±2dBmMCS020±2dBm
    802.11n HT40MCS718±2dBmMCS020±2dBm
    802.11ac HT80MCS917±2dBmMCS019±2dBm
    2.4G Receive Sensitivity802.11b11M-85dBm1M-94dBm
    802.11g54M-72dBm6M-90dBm
    802.11n HT20MCS7-70dBmMCS0-88dBm
    802.11n HT40MCS7-68dBmMCS0-86dBm
    5G Receive Sensitivity802.11a54M-72dBm6M-90dBm
    802.11n HT20MCS7-70dBmMCS0-88dBm
    802.11n HT40MCS7-68dBmMCS0-86dBm
    802.11ac HT80MCS9-58dBmMCS0-85dBm
    EVM

    2.4G EVM: 802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28dB
    5G EVM: 802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB

    PPM±20ppm
    Max Users256
    Firmware Features:
    Operation modeWireless AP, Gateway, WISP, Wi-Fi Repeater
    WAN TypeDynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access)
    Wireless Security64/128-bit WPA / WPA2(PSK/AES) encryption
    SSIDMultiple SSID (4 SSID for 2.4G, 8 SSID for 5.8G)
    FirewallIP Address Filter/MAC Address Filter/Domain Filter
    IP and MAC Address Binding
    ProtocolsIPv4
    Others:
    Package Contents

    2200Mbps Dual Band wireless access point
    Ethernet Cable
    Quick Installation Guide
    Setting Accessory

    System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, MAC OS, NetWare, UNIX or Linux
    Environment

    Operating Temperature: -20~55 ℃
    Limit working temperature: -30~70 ℃
    Storage Temperature: -40~70 ℃
    Humidity: 5%~95% non-condensing

    ManagementFirmware GUI, Remote Management, WLAN Controller, Cloud Management System



    Accessory:

    •  HW-AP2200 Unit
    •  Installation Accessory
    •  6PCS 6dBi Omni antennas(Optional)
