Place of Origin: | China |
Brand Name: | Yuncore |
Certification: | CE,FCC,ROHS |
Model Number: | OLTE300 |
Minimum Order Quantity: | 100 PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Giftbox + Carton box |
Delivery Time: | 4 working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 500 PCS/ WEEK |
Material: | Metal | Chipset: | AR9531 |
---|---|---|---|
4G LTE SIM Card Slot: | Supported | 4G LTE Module: | Built-In |
Data Rate: | 300Mbps | Interface: | SIM Card Slot, RJ45 Port And PoE Support |
High Light: | outdoor wireless ap,access point base station |
Product Specification:
|
|||
Hardware: | |||
Chipset | Qualcomm QCA9531 | ||
Frequency | 550MHz | ||
WiFi Standard | 2.4G 802.11b/g/n ; 300M MIMO technology | ||
Memory | 128MB DDR RAM | ||
Flash | 16MB | ||
Interface | WAN / LAN Port: 1 * 10/100 Mbps RJ45 Port | ||
Reset button: Press it with 10 second, product with default data | |||
SIM Card Slot: work with 3G/4G data card | |||
Antenna | SMA Connector, can connect with external omni/panel antenna | ||
Power | PoE: IEEE 802.3af, 48V | ||
Power Consume | >10W | ||
RF Data | |||
RF Data | 2.4G: 802.11b/g/n | ||
2.4GHz | |||
Modulation Scheme | OFDM = BPSK,QPSK, 16-QAM, 64-QAM 256-QAM | ||
DSSS = DBPSK, DQPSK, CCK | |||
Data Rate | 300Mbps | ||
Receive Sensitivity | 802.11n(2.4GHz) | 802.11g | 802.11b |
-90dBm @ MCS0 | - 90dBm @ 6Mbps | - 95dBm @ 1Mbps | |
-72dBm @ MCS7 | - 72dBm @ 54Mbps | - 90dBm @ 11Mbps | |
-90dBm @ MCS8 | |||
-68dBm @ MCS15 | |||
RF Output Power | |||
802.11n(2.4GHz)(± 1.5dBm) | 802.11g(± 1.5dBm) | 802.11b(±1.5dBm) | |
28dBm@ MCS0~2/MCS8~10 | 28dBm @ 6~24Mbps | 28dBm @1~11Mbps | |
28dBm @ MCS3/MCS11 | 27dBm @ 36Mbps | ||
27dBm @ MCS4/MCS12 | 27dBm @ 48Mbps | ||
27dBm @ MCS5/MCS13 | 26dBm @ 54Mbps | ||
26dBm @ MCS6/MCS14 | |||
26dBm @ MCS7/MCS15 |
