Place of Origin: | China |
Brand Name: | Yuncore |
Certification: | CE,FCC,ROHS |
Model Number: | MT876 |
Minimum Order Quantity: | 1000 PCS |
---|---|
Price: | Negotiable |
Packaging Details: | Giftbox + Carton box |
Delivery Time: | 4 working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 1000 PCS/ WEEK |
Material: | ABS | Chipset: | MTK 7620N |
---|---|---|---|
Flash: | 8M | RAM: | 64M |
Band: | 2.4GHz-2.483GHz | Port: | 1*10/100 WAN, 4*10/100 LAN |
High Light: | 300mbps wireless n router,wireless n dual band router |
Standard | IEEE 802.11n,IEEE 802.11g,IEEE 802.11b,CSMA/CA,CSMA/CD,TCP/IP,DHCP,ICMP,NAT,PPPoE | ||
Interface |
LAN 4 10/100M Auto MDI/MDIX RJ45 ports.; WAN 1 10/100M Auto MDI/MDIX RJ45 port WPS Reset button USB 2.0 port |
||
Frequency Band | 2.4GHz-2.4835GHz | ||
Data Rate |
11n: 300/270/243/216/162/108/81/54/27Mbps 135/121.5/108/81/54/40.5/27/13.5Mbps 130/117/104/78/52/39/26/13Mbps 65/58.5/52/39/26/19.5/13/6.5Mbps 11g: 54/48/36/24/18/12/9/6M(adaptive) 11b: 11/5.5/2/1M(adaptive) |
||
Wireless Transmit power |
11b: 20±1 dBm 11g:: 16±1 dBm 11n:: 15±1 dBm) |
||
Transmission Distance | Indoor :100m | ||
Access Protocol | CSMA/CA,CSMA/CD,TCP/IP,ICMP,NAT,PPPoE, DHCP , Wired static , Wifi Client ,UDP, DDNS, | ||
Security | WEP 64/128bit;MAC based Association; SSID broadcast disable; Wi-Fi Protection Access (TBD),WPA,WPA2, Built-in firewall | ||
RF Output Power(Typical) | 802.11n:15dBm for OFDM mode | ||
802.11g: 17dBm for OFDM mode | |||
802.11b: 20dBm fro CCK mode | |||
Receive Sensitivity |
11n : -70dBm@10% PER 11g : -70dBm@10% PER 11b: -85dBm@8% PER |
||
Channels: |
2412~2462 MHz (US) 11 channels 2412~2472 MHz (EU) 13 channels 2412~2484 MHz (Japan) 14 channels |
||
WLAN Modulation Scheme | BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) | ||
SDRAM | 64M | ||
Flash | 8M | ||
Antenna | three un-detachable 5dBi Antenna | ||
LED | POWER, Internet, Wlan, Lan/Wan, External power supply | ||
Operation Temperature | 0°C ~ 40°C ambient temperature | ||
Storage Temperature | -20% ~ 70% ambient temperature | ||
Humidity | 10% ~ 90% (Non-condensing) | ||
Power | (Output DC5V, 1A;Input 110V/220V) | ||
Support system | Windows® 2000, XP 32/64, Vista 32/64, Linux,MAC,Windows 7 |
Working Diagram:
